Made To Drain

Engineered Floor Troughs

We manufacture products that:
- Contain water and eliminate leaks above and below commercial flooring applications
-Redirect water and debris to improve safety and sanitation

Slider
PHONE: 866-895-7264   •   EMAIL: info@madetodrain.com

ABOUT US

Made to Drain manufactures products that:

  • contain water and eliminate leaks above and below commercial flooring applications
  • redirect water and debris to improve safety and sanitation
PHONE: 866-895-7264   •   EMAIL: info@madetodrain.com

OUR PRODUCTS

Floor Troughs

Anti-Splash Floor Troughs

Drain Pans

Clog-Free™

With high capacity strainer tray

Leak Eliminator

Clog-Free™

With high capacity strainer tray

  • Virtually eliminates building drain clogs. No more building maintenance service calls
  • Fewer clogs mean no trough overflow and leaks through surrounding tile and grout
  • Significantly decreases the amount of sediment entering grease traps; grease traps will work more efficiently
  • Decreased sediments reduce grease trap clogs and extends service intervals
  • Better housekeeping
  • No free standing water
  • Minimizes slips and falls

VIDEO    |    SPEC SHEET    |    REVIT

Floor Troughs

  • Floor Toughs complement Clog-Free® line of floor troughs
  • Designed for areas where liquids are a problem
  • Manufactured and pitched to keep water and liquids draining rather than pooling
  • Custom anti-fatigue and non-slip grating system provides comfortable, safe working surface
  • Grout locking holes around flange perimeter ensure complete seal of the grout to the pan.

SPEC SHEET    |    REVIT

Anti-Splash Floor Troughs

  • Anti-Splash Floor Troughs keep water and liquids draining rather than pooling
  • 60° bend prevents splash
  • Pitched 1" (25) on each end to direct liquids to center drain(s)
  • Troughs 96" (2438) and longer come with two drains
  • Fiberglass grates are made from reinforced, anti-slip resin and offer an integral built-in flex to reduce employee fatigue
  • Removable grates can be cleaned in conveyor or door type dish machines
  • Weight capacity ranges from 1,425 lbs (646 kg) to 3,500 lbs (1591 kg) per grate.

SPEC SHEET    |    REVIT

Drain Pans

  • For use under equipment such as kettles, braising pans, steamers or ice machines
  • Provides seamless, watertight seal beneath equipment and protects from leaking into occupied spaces below
  • Eliminates free standing water
  • Replaces materials such as porous floor tile and grouted seams that become susceptible to leaks due to exposure to heat, moisture, food acids, expansion and contraction
  • 1/4″ per foot pitch allows drainage of water during equipment operation and cleaning

SPEC SHEET    |    REVIT

Leak Eliminator



  • For use in above-grade floor trough installations
  • Uniquely designed (patent pending) to solve the age-old problem of floor trough leaks into occupied spaces below
  • Seepage flange mates to floor trough and clamps down on waterproof membrane to create watertight seal
  • Weep holes in seepage flange allow liquids to freely flow into building drain line to prevent accumulation and leaking into occupied spaces below
  • Fits with all Made to Drain Troughs
  • Easy to install
  • Proactive solution for troughs that may leak

SPEC SHEET    |    REVIT

REVIT DRAWINGS

To access and download the Revit drawings for products, click the icon to the left or click here.

To find and discuss your product and purchasing options with the Made to Drain rep closest to you, click here to use our Rep Finder.
